Paper Mill Waste Shredder

Input Size : Customize

Output Capacity : 200-10000kg/h

Product Application : Waste paper packaging station, paper factory, document destruction industry, etc

Applicable Material : Waste corrugated paper, paper pipe, paper core, paper roll, paper, hard paper, book paper, newspaper, jam paper and other paper materials

Product Description

You can shred waste paper, cardboard, and rolls of paper with our shredders, improving the return on your paper recycling.

With so many options, we can optimize your shredder for your specific material, guaranteeing the best possible performance.

  • pape mill waste

    Pape Mill waste

  • pape mill waste

    Magazines/Book destruction

  • pape mill waste

    Pulper Rope waste

  • paper waste

    Paper waste

APPLICABLE

Paper and paper mill waste

Pulp ropes

Other industrial and domestic waste +

WORKING PRINCIPLE

Waste Paper Shredder is driven by the independently double-roller.During the production the material will be pressed accordingly for automatic feed .During the production process of low speed and high torque, there is no spindle entanglement, or jammed equipment,thus improving the production efficiency, the equipment is suitable for various waste paper products crushing .

FEATURES

● Low speed, large torque, Low noise, low dust;

● Hydraulic feeding system, swinging arm forced feeding structure; 180° turnover, the knife body utilization rate is higher;

● Reduction gearbox swinging arm installation structure, micro switch monitoring, protect the internal gear and motor;

● Imported SKD11, D2, DC53, ASP60 blades, high strength, wear resistance, long life;

● Feeding test for 80~100 hours before delivery to ensure the reliability of the equipment.

FINAL PRODUCT

  • shredding effect
  • papermillwaste
  • shredding effect
  • shredding effect

Technical Parameters

Model Power (KW) Rotating speed (r/min) Dimensions L/W/H(mm) Crushing cavity size C/D(mm) Diameter of knife body (mm)
XCS-56 15+15 6-20 2800×1300×1850 600×500 220
XCS-58 18.5+18.5 6-20 3000×1300×1850 800×500 220
XCS-710 30+30 6-20 3300×1900×2200 1000×700 320
XCS-812 37+37 6-20 3600×2000×2200 1200×800 400
XCS-815 45+45 6-20 4180×2100×2400 1500×850 450
XCS-918 75+75 6-20 5800×2400×3300 1800×900 500
XR-1020 90+90 6-20 6400×2700×3500 2000×1000 600
XR-1522 110+110 6-20 7800×3200×3800 2200×1500 800
